一、进口V型球阀概述

进口V型球阀（美国威盾VTON），type-V-flanged ball valve，也叫V型球芯阀，V型切断球阀，是一种芯阀座采用金属，或金属对聚四氟乙烯密封配合的旋转球阀，它将球阀和蝶阀的最佳控制特性结合成一体,既可用作控制调节阀，又可作关断切断阀。

美国威盾VTONV型球阀主要产品有法兰V型球阀, 气动V型球阀，电动V型球阀，V型对夹球阀， V型不锈钢球阀，主要用于输送纤维和纸浆等介质.球体上的V型缺口能起切断作用,以避免纤维物料粘在球体.阀体和阀座之间,另外V型球还广泛用来调节流量。

V-shaped Ball Valve, also known as V-shaped Ball Valve or V-shaped Cut off Ball Valve, is a rotary ball valve with a metal or metal to PTFE sealing fit. It combines the best control characteristics of the ball valve and butterfly valve, and can be used as a control regulating valve or a shut-off valve.

The main products of American Weidun VTONV ball valves include flange V-shaped ball valves, pneumatic V-shaped ball valves, electric V-shaped ball valves, V-shaped clamp ball valves, and V-shaped stainless steel ball valves. They are mainly used for conveying media such as fibers and pulp. The V-shaped notch on the ball can cut off the fiber material to prevent it from sticking between the ball body, valve body, and valve seat. In addition, V-shaped balls are also widely used to regulate flow.

二、进口V型球阀|V型球心阀特点

（１）V型球阀|V型球心阀不带任何管接头的整体式阀体，因此不受管道或螺栓应力影响，并且由于阀体无任何管接头，故耐压壳体不会受压力“突变”的影响；
（２）V型球阀|V型球心阀具有一个Ｖ型阀体，即使在小流量或高粘度介质的情况下，也可在整个量程范围内，保证控制的精确性；
（３）防漏耐用的阀座在其外径处衬有带不锈钢内芯ＰＴＦＥ杯形或是Ｏ型密封圈，阀座用截面较大的钨钴硬质合金制成，通过一个合金的波纹弹簧进一步增强了阀座的结构；
（４）V型球阀|V型球心阀当阀门关闭时，Ｖ型缺口与阀座之间产生楔形剪切作用，并既具有自洁功能又可防止球芯卡死，特别适用于高粘度、悬浮液、纸浆等不干净、含纤维介质场合。

(1) V-shaped ball valve | V-shaped ball valve is an integral valve body without any pipe joints, so it is not affected by pipeline or bolt stress, and because the valve body has no pipe joints, the pressure resistant housing will not be affected by pressure "sudden changes";

(2) V-shaped ball valve | V-shaped ball valve has a V-shaped valve body, which can ensure control accuracy throughout the entire range even in low flow or high viscosity media;

(3) The leak proof and durable valve seat is lined with a PTFE cup or O-ring with a stainless steel inner core at its outer diameter. The valve seat is made of tungsten cobalt hard alloy with a larger cross-section, and the structure of the valve seat is further enhanced by an alloy ripple spring;

(4) V-shaped Ball Valve | V-shaped Ball Valve When the valve is closed, a wedge-shaped shear effect occurs between the V-shaped notch and the valve seat, and it not only has self-cleaning function but also prevents the ball core from getting stuck. It is especially suitable for high viscosity, suspension, pulp and other unclean and fiber containing media.

三、进口V型球阀|V型球心阀产品性能规范
