一、进口螺纹带焊接管球阀概述

进口螺纹带焊接管球阀（美国威盾VTON），Threaded pipe with welded ball valve，也叫液压阀 液压球阀 高压球阀 外螺纹带焊接管高压球阀,焊接式高压球阀,外螺纹焊接高压球阀 板式高压球阀 不锈钢高压球阀 天然气高压球阀。

是指采用外螺纹连接，并带活接焊接管的球阀，安装方便。具有体积小、抗震动的特点。是由三部分阀壳组成，由四只较长螺栓从两端夹住中间阀体与阀球而成。其优点是维修拆卸时不用拆卸管路螺纹，而直接拆卸四只螺栓，阀体中间部分既可取出。适用于液压系统管路中，作接通和切断用，主阀采用优质锻钢件，表面进行镀铬处理，外表美观，操作方便，密封性能可靠。

Thread pipe with welded ball valve, also known as hydraulic valve, hydraulic ball valve, high-pressure ball valve, external thread with welded pipe high-pressure ball valve, welded high-pressure ball valve, external thread welded high-pressure ball valve, plate type high-pressure ball valve, stainless steel high-pressure ball valve, natural gas high-pressure ball valve

It refers to a ball valve that is connected with external threads and comes with a union welded pipe, which is easy to install. It has the characteristics of small volume and anti vibration. It is composed of three parts of valve casing, consisting of four longer bolts clamping the middle valve body and valve ball from both ends. Its advantage is that during maintenance and disassembly, there is no need to dismantle the pipeline threads, and the four bolts can be directly removed. The middle part of the valve body can be taken out. Suitable for connecting and cutting hydraulic system pipelines, the main valve is made of high-quality forged steel parts with chrome plating treatment on the surface, which has a beautiful appearance, convenient operation, and reliable sealing performance.

二、进口螺纹带焊接管球阀参数

口径：DN3-50

公称压力：1.6-50MPa

适用温度范围：-20～180℃

材质：锻钢，不锈钢304、316、316L

连接方式：螺纹带焊接管

适用介质：天然气、高压油、液压系统、矿物油，水，乙二醇，其他混合液体

三、进口螺纹带焊接管球阀产品特点

1、防火、防静电设计

2、阀杆防爆出装置

3、阀球上设计有压力平衡孔

4、双层阀杆填料与对压碟型弹片装置

5、主阀采用优质锻钢件，表面进行发黑或镀铬处理。外表美观，操作方便，密封性能可靠。

1. Fireproof and anti-static design

2. Valve stem explosion-proof outlet device

3. Pressure balancing holes are designed on the valve ball

4. Double layer valve stem packing and pressure disc type spring device

5. The main valve is made of high-quality forged steel parts, and the surface is treated with blackening or chrome plating. Beautiful appearance, easy operation, and reliable sealing performance.
