一、进口铸钢/碳钢闸阀概述

进口铸钢/碳钢闸阀，Cast steel gate valve，是指采用美国威盾优质上等的铸钢/碳钢/WCB材质，采用法兰连接方式的闸阀。闸阀的启闭件是闸板，闸板的运动方向与流体方向相垂直，闸阀只能作全开和全关，不适合作调节和节流。是最常用的截断阀之一，主要用来接通或截断管路中的介质，不适用于调节介质流量。铸钢闸阀适用的压力、温度及口径范围很大，尤其适用于中、大口径的管道。

美国威盾进口铸钢/碳钢闸阀主要产品有：进口铸钢闸阀，进口碳钢闸阀，进口美标闸阀，进口蒸汽闸阀，进口水用闸阀，进口气体闸阀，楔式闸阀、刀型闸阀、弹性座封闸阀、JIS日标、ANSI美标闸阀、夹套保温闸阀、浆液阀、锻钢闸阀、平板闸阀、暗杆闸阀、真空闸阀等系列产品。

Cast steel/carbon steel gate valves, Cast steel gate valve， It refers to a gate valve made of high-quality cast steel/carbon steel/WCB material from the American shield, and connected by flange. The opening and closing component of a gate valve is the gate, and the direction of the gate's movement is perpendicular to the direction of the fluid. The gate valve can only be fully open and fully closed, and is not suitable for adjustment and throttling. It is one of the most commonly used shut-off valves, mainly used to connect or cut off the medium in the pipeline, and is not suitable for regulating the medium flow rate. Cast steel gate valves are suitable for a wide range of pressure, temperature, and diameter, especially for medium and large diameter pipelines.

The main products of American Weidun imported cast steel/carbon steel gate valves include: cast steel gate valves, carbon steel gate valves, American standard gate valves, steam gate valves, water gate valves, gas gate valves, wedge gate valves, knife gate valves, elastic seat seal gate valves JIS Japanese standard ANSI American standard gate valves, jacketed insulation gate valves, slurry valves, forged steel gate valves, flat gate valves, non rising stem gate valves, vacuum gate valves and other series of products.

二、进口铸钢/碳钢闸阀参数

1、公称压力或压力级：PN1.0-16.0MPa、ANSI CLASS 150-1500LB、JIS10-20K

2、公称通径或口径：DN10～1000、NPS 1/2 ～36"

3、连接方式：法兰、对焊、螺纹等

4、适用温度：-196℃～700℃

5、驱动方式：手动、伞齿轮传动、气动、电动、液动、气液联动、电液联动

6、阀体材料：WCB，碳钢，铸钢

7、适用介质：水、蒸汽、油品、硝酸、醋酸、氧化性介质、尿素等多种介质。

三、进口铸钢/碳钢闸阀优点

1、铸钢/碳钢闸阀结构紧凑，设计合理，阀门刚性好，通道流畅，流阻系数小。

2、铸钢/碳钢闸阀密封面为不锈钢或硬质合金，使用寿命长。

3、铸钢/碳钢闸阀采用石棉石墨或柔性石墨，密封可靠，操作轻便灵活。

4、铸钢/碳钢闸阀可采用各种配管法兰标准及法兰密封面形式，有美标，德标，日标和中国国标标准满足各种工程需要及用户要求。

5、铸钢/碳钢闸阀广泛应用于石油、化工、水力、火力电站各种系统的管路上。

1. Cast steel/carbon steel gate valves have a compact structure, reasonable design, good valve rigidity, smooth channels, and low flow resistance coefficient.

2. The sealing surface of cast steel/carbon steel gate valves is made of stainless steel or hard alloy, with a long service life.

3. Cast steel/carbon steel gate valves are made of asbestos graphite or flexible graphite, with reliable sealing and easy and flexible operation.

4. Cast steel/carbon steel gate valves can adopt various piping flange standards and flange sealing surface forms, including American standards, German standards, Japanese standards, and Chinese national standards to meet various engineering needs and user requirements.

5. Cast steel/carbon steel gate valves are widely used in pipelines of various systems in petroleum, chemical, hydraulic, and thermal power plants.
