一、进口卡箍式卫生型电磁流量计概述

进口卡箍式卫生型电磁流量计是采用不锈钢材质，卡箍快装的连接方式，能够很方便的快速拆卸、清洗，使电磁流量计在使用过程中不易被污染，且能有效防止测量流体残余物在测量管中的堆积，可广泛应用于矿泉水、酱油、果酱、啤酒、果汁、米酒、牛奶等食品的生产制造过程及卫生、化工等领域。

The clamp type sanitary electromagnetic flowmeter is made of stainless steel material with a quick installation connection method, which can be easily and quickly disassembled and cleaned, making the electromagnetic flowmeter less prone to contamination during use and effectively preventing the accumulation of residual measuring fluid in the measuring tube. It can be widely used in the production and manufacturing process of mineral water, soy sauce, jam, beer, fruit juice, rice wine, milk and other food products, as well as in the fields of hygiene, chemical industry, etc.

二、进口卡箍式卫生型电磁流量计特点

1、卫生型卡箍式电磁流量计采用304全不锈钢材质；

2、衬里根据客户的不同要求，可以选用聚氯丁橡胶、聚四氟乙烯、聚全氟乙烯F46等；

3、电极形式可采用：含钼不锈钢、哈氏B、哈氏C、钛、钽、铂、电极多种选择，供客户参考；

4、供电方式：220V、24V DC；

5、转换器精度高，信号好；

6、通过红外线触摸按键设定参数，在恶劣的环境下不打开转换器的盖板也可以安全的进行设定；

7、转换器具有自诊断报警、空负载检测报警、流量上下限报警及两极流量值报警输出等功能；

8、高清晰度背光LCD显示，全中文菜单操作，使用方便，操作简单，易学易懂；

9、具有RS485、RS232、Hart和Modbus等数字通讯信号输出。

1. The sanitary clamp type electromagnetic flowmeter adopts 304 all stainless steel material;

2. According to different customer requirements, the lining can be made of polychloroprene rubber, polytetrafluoroethylene, polytetrafluoroethylene F46, etc;

3. The electrode form can be selected from various options including molybdenum containing stainless steel, Hastelloy B, Hastelloy C, titanium, tantalum, platinum, and electrodes for customer reference;

4. Power supply mode: 220V, 24V DC;

5. The converter has high accuracy and good signal;

6. By using infrared touch buttons to set parameters, it is safe to set without opening the cover of the converter in harsh environments;

7. The converter has functions such as self diagnostic alarm, empty load detection alarm, flow upper and lower limit alarm, and bipolar flow value alarm output;

8. High definition backlit LCD display, all Chinese menu operation, convenient to use, simple to operate, easy to learn and understand;

9. Equipped with digital communication signal outputs such as RS485, RS232, Hart, and Modbus.
