一、进口冷媒增压泵概述

威盾VTON的冷媒增压泵，Refrigerant booster pump，是双作用液体增压泵。专门设计的换向阀与泵体装配在一起，自动换向，驱动活塞往复运动一次，完成两次吸入与高压排出。驱动缸、缸盖采用铝合金型材加工，材质致密，避免微裂纹压力损失，外形整洁美观。

冷媒增压泵的道理是基于驱动活塞和加压活塞面积比差别的高压,归因于气动加压产品,不过凭据冷媒,冷媒的物理特征,缸体质料的选定304不锈钢氧化处分,密封圈选定聚四氟乙烯和少许低柔顺耐磨性和侵蚀性质料。

The refrigerant booster pump of Weidun VTON， It is a double acting liquid booster pump. The specially designed directional valve is assembled with the pump body, automatically reversing and driving the piston to reciprocate once, completing two suction and high-pressure discharge operations. The drive cylinder and cylinder head are processed with aluminum alloy profiles, which are dense in material, avoiding micro crack pressure loss, and have a clean and beautiful appearance.

The principle of refrigerant booster pump is based on the high pressure caused by the difference in the area ratio between the driving piston and the pressurizing piston, which is attributed to pneumatic pressurization products. However, based on the physical characteristics of the refrigerant, 304 stainless steel oxidation treatment is selected for the cylinder body material, and polytetrafluoroethylene and a small amount of low flexibility, wear resistance, and corrosive materials are selected for the sealing ring.

二、进口冷媒增压泵应用范围

1、适应于R22、R134a、R407C、R410A等各种冷媒的输送。

2、制冷行业：制冷剂填充量在100kg以上的机组维修或生产加注。

3、制冷行业：制冷剂加注或常压制冷剂的加压工作。

4、制冷剂生产行业：制冷剂的灌装及大罐残液的回收。

1. Suitable for transporting various refrigerants such as R22, R134a, R407C, R410A, etc.

2. Refrigeration industry: Maintenance or production filling of units with refrigerant filling capacity of over 100kg.

3. Refrigeration industry: refrigerant charging or pressurization of atmospheric pressure refrigerants.

4. Refrigerant production industry: refrigerant filling and recovery of residual liquid from large tanks.

三、进口冷媒增压泵产品特点

1、专门设计的换向阀与泵体装配在一起，自动换向，驱动活塞往复运动一次，完成两次吸入与高压排出。

2、驱动缸、缸盖采用铝合金型材加工，材质致密，避免微裂纹压力损失，外形整洁美观。

3、作用缸筒采用满吸设计，并采用高质量不锈钢整体淬火精密加工，长期工作磨损小，无变形，无渗漏。

4、泵的进出口单向阀采用与作用缸不同材质的不锈钢精密加工，保压可靠。

5、专用的换向阀确保驱动换向、相同气压下泵动作频次高，可靠性高。

6、整套机构摩擦力矩低，压力损失小，极低启动气压，确保增压迅速，泵运行稳定，效率高，噪声低。

1. The specially designed directional valve is assembled with the pump body, automatically reversing and driving the piston to reciprocate once, completing two suction and high-pressure discharge operations.

2. The drive cylinder and cylinder head are processed with aluminum alloy profiles, which are dense in material, avoiding micro crack pressure loss, and have a clean and beautiful appearance.

3. The action cylinder adopts a full suction design and is precision machined with high-quality stainless steel quenching. It has low long-term wear, no deformation, and no leakage.

4. The inlet and outlet check valves of the pump are made of stainless steel precision machined from a material different from that of the action cylinder, ensuring reliable pressure maintenance.

5. The dedicated directional valve ensures high frequency and reliability of pump operation under the same pressure and driving direction.

6. The entire mechanism has low friction torque, minimal pressure loss, extremely low starting air pressure, ensuring rapid pressurization, stable pump operation, high efficiency, and low noise.
