一、进口氢气增压加压泵概述

威盾VTON的氢气增压加压泵，Hydrogen booster booster pump，也叫氢气增压加压机，采用单气控非平衡气体分配阀来实现泵的往复运动，全部采用铝合金及不锈钢制造。全部密封均为进口优质产品，最大设计驱动气压均为10bar，为了保证泵的寿命建议驱动气压<8bar。该系列泵的驱动活塞直径为160mm，为单作用泵，所有单作用泵均带有排气冷却。
氢气增压系统属于二级增压。广泛应用于钢铁、电力、冶金、制造、造船、电子、纺织、矿山、石油化工、造纸印刷、机械制造、食品医疗、汽车工业、航空航天等领域。满足客户对一些高精度电子仪器产品生产、实验过程的检测以及氢气、氮气、氩气、甲醇、一氧化碳、二气化碳、天然气、液化气等特种气体压缩，输送，灌瓶及燃气汽车加气。

The hydrogen booster pump of Weidun VTON, Hydrogen booster booster pump， Also known as a hydrogen booster compressor, it uses a single gas controlled non-equilibrium gas distribution valve to achieve the reciprocating motion of the pump, all made of aluminum alloy and stainless steel. All seals are imported high-quality products, and the maximum designed driving pressure is 10 bar. To ensure the service life of the pump, it is recommended that the driving pressure be less than 8 bar. The drive piston diameter of this series of pumps is 160mm, which is a single acting pump. All single acting pumps are equipped with exhaust cooling.

The hydrogen boosting system belongs to the second stage boosting. Widely used in fields such as steel, electricity, metallurgy, manufacturing, shipbuilding, electronics, textiles, mining, petrochemicals, paper and printing, machinery manufacturing, food and medical care, automotive industry, aerospace, etc. Satisfy customers' requirements for the production and testing of high-precision electronic instrument products, as well as the compression, transportation, bottling, and refueling of special gases such as hydrogen, nitrogen, argon, methanol, carbon monoxide, carbon dioxide, natural gas, liquefied gas, and gas vehicles.

二、进口氢气增压加压泵产品特点

1、性价比高：威盾增压泵是一种活塞式泵，工作时，泵迅速往复工作，随着压力的增高，泵的往复速度减慢直至停止，此时，泵的输出压力恒定，能量消耗最低，各部件停止运动，由于是活塞式泵，其结构简单易于维护，大大降低了维护成本。

2、可带压力启动，被增压介质出口具有一定压力的情况下，泵可以在停止的状态下使用，不限制启停次数。

3、采用低压驱动实现高压，可以通过调节低压气体的压力实现被增压介质的压力无极可调。

4、自动补压：在驱动气压不变的情况下，当被增压介质压力降低时，泵可自动启动，实现补压功能。在关闭驱动气压的情况下，自动补压功能取消。

5、不锈钢材质，无需电源，防腐防爆。

1. High cost-effectiveness: The Weidun booster pump is a piston pump that rapidly reciprocates during operation. As the pressure increases, the reciprocating speed of the pump slows down until it stops. At this point, the output pressure of the pump remains constant, energy consumption is minimized, and all components stop moving. As a piston pump, its structure is simple and easy to maintain, greatly reducing maintenance costs.

2. The pump can be started with pressure, and when the outlet of the pressurized medium has a certain pressure, it can be used in a stopped state without limiting the number of starts and stops.

3. By using low-pressure drive to achieve high pressure, the pressure of the pressurized medium can be infinitely adjustable by adjusting the pressure of the low-pressure gas.

4. Automatic pressure compensation: When the pressure of the pressurized medium decreases while the driving air pressure remains constant, the pump can automatically start to achieve pressure compensation function. The automatic pressure compensation function is cancelled when the driving air pressure is turned off.

5. Stainless steel material, no need for power supply, anti-corrosion and explosion-proof.

三、进口氢气增压加压泵应用范围

1、应用于氢气回收，氢气压缩，氢气增压等。

2、适合于高压反应釜氢气增压；氢气加氢反应；氢气回收。（产品采用低压空气驱动，没有电火花危险）

3、氢气压缩试验等场合。

1. Applied to hydrogen recovery, hydrogen compression, hydrogen pressurization, etc.

2. Suitable for hydrogen pressurization in high-pressure reactors; Hydrogen hydrogenation reaction; Hydrogen recovery. (The product is driven by low-pressure air and there is no risk of electric sparks)

3. Hydrogen compression test and other occasions.
